POWERTRAINS

At ORE Catapult, we are at the forefront of powertrain testing, validation, engineering and research. Our experienced powertrain specialists, engineering and project management teams work with clients to enhance and validate their advanced and complex wind and tidal turbine powertrain systems.

Download Brochure

Across our facilities, we carry out:

Highly Accelerated Lifetime Testing (HALT) with multi-axis loading

System performance tests; power curve and efficiency assessments

Design verification and model validation

Worldwide grid compliance testing

Component validation and conformance testing

New supply chain validation

POWERTRAIN TESTING & VALIDATION FACILITIES

Located in our Blyth location, we have state-of-the-art testing and validation facilities for next generation offshore wind turbine systems that can perform powertrain endurance, extreme load and bearing testing.

Here is a list of our capabilities:

15MW powertrain test facility

Powertrain testing facility for offshore wind turbine systems, with 6 degrees of freedom loading and grid emulation

3MW powertrain test facility

Horizontal axes powertrain testing facility for wind and tidal turbine systems, with 6 degrees of freedom loading and grid emulation

1MW powertrain test facility

Sub-megawatt powertrain and component testing facility for small scale turbine powertrain systems

18MVA grid emulation system (eGRID)

One of the world’s most advanced grid emulation systems, enabling simultaneous mechanical and electrical system testing in conjunction with our powertrain test facilities.

Data acquisition & analysis

With 840 GPS–synchronised channels available, our data acquisition and analysis service enables us to measure every aspect of a powertrain’s performance, while securely and independently managing client measurement data.

Wind load characteristics using our 7MW demonstration turbine

We emulate powertrain test conditions with real-time, in-field operating conditions, assisting clients in building accelerated test load profiles from field operational loading conditions.

Materials analysis

Our materials specialists and fully equipped in-house laboratories allow clients to better understand turbine behaviour, failure modes and root cause, as well as perform post-test tear down inspections. We offer tear down and analysis, dedicated HV Materials Lab on-site and an understanding of root cause of failures.

Testing at ORE Catapult is an important step in our engineering process and the data collected will play a critical role in future design considerations. We plan to continue to invest in both onshore and offshore testing.”

SIMEC Atlantis Energy

POWERTRAIN RESEARCH HUB

The Powertrain Research Hub is a £2.5m partnership between the University of Sheffield and GE Renewable Energy. The hub focuses on the development of next generation and future technologies and research solutions for improving turbine reliability and performance. Our powertrains expertise supports with accelerated lifetime testing of the latest and greatest nacelles in offshore wind and tidal energy.
